| مكان المنشأ: | شنتشن الصين |
|---|---|
| اسم العلامة التجارية: | TeXin |
| إصدار الشهادات: | CE ISO |
| رقم الموديل: | تكتشف TX |
| الحد الأدنى لكمية: | 1 |
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | حالة متينة |
| وقت التسليم: | 10-15 أيام |
| شروط الدفع: | L/C ، D/A ، D/P ، T/T ، Western Union ، Moneygram |
| القدرة على العرض: | 100/شهر |
| اسم: | كاشف | نطاق الكشف المنتظم: | 5km （بيئة راديو جيدة） |
|---|---|---|---|
| نطاقات تردد الكشف: | 0.7-6.3 جيجا هرتز/ 2.4-2.5 جيجا هرتز/ 5.15-5.95 جيجا هرتز | زاوية الكشف: | 360 درجة |
| مسافة الكشف: | ＞ 2 كم (OFDM) ＞ 4km (FPV 5.8G/2W) | مزود الطاقة: | DC 4.75 ~ 36V |
| درجة الحماية: | IP65 | درجة حرارة العمل: | 40 ~ +70 ℃ |
| إبراز: | long range drone detector,outdoor drone signal detector,360 degree FPV drone detector,outdoor drone signal detector,360 degree FPV drone detector |
||
This detector boasts an impressive 5km detection range—far exceeding standard consumer-grade detectors. Whether in open fields, industrial complexes, or large event venues, it can identify approaching drones at an early stage, providing ample time for security personnel to assess the situation, issue alerts, and take response measures.
Our detector addresses this by covering an extensive frequency spectrum of 700-6300MHz—a range that encompasses most common drone communication and control bands. This product features 360° omni-directional detection capability. Its specially designed antenna array ensures uniform signal reception across all angles.
| Regular detection range | 5km (Good radio environment) |
|---|---|
| Detection frequency bands | 0.7-6.3GHz/ 2.4-2.5GHz/5.15-5.95GHz |
| Identify Type | FPV Simulation Image Transmission OFDM HD Image Transmission |
| Detection angle | 360° |
| Sensitivity | Better than -96dBm (FPV signal Bw=6MHz) Better than -90dBm (OFDM signal Bw=20MHz) |
| Detection distance | ＞2km (OFDM) ＞4km (FPV 5.8G/2W) (The measured reliable distance when using a 2dBi gain receiving antenna. The actual antenna gain increases by 6dB, and the detection distance can be doubled.) |
| UART Parameters | 115.2kbps/TTL3~5V compatible |
| Power supply | DC 4.75 ~36V |
| Power consumption | ＜3.5W |
| Weight | 13.2kg |
| Volume | 470mm x 352mm |
| Protection grade | IP65 |
| Working temp | -40 ~ +70℃ |
